Panasonic- AW-UE80WPJ

Panasonic 4K60 SDI/HDMI/NDI PTZ Camera with 24x Optical Zoom

Manufacturer: Panasonic
Category: PTZ Cameras
SKU: AW-UE80WPJ
Availability: Call
MSRP: $6,145.00
PRODUCT HIGHLIGHTS

Perfect for a wide range of video production needs, such as recording of reality shows and events.

Compact design and quiet operation for smooth integration with the surroundings.
The compact size and dome shape make the camera's movements virtually unnoticeable. The new direct-drive motor has reduced the operating sound to NC25 or lower. Quiet operation makes the performers less conscious of the presence of the camera during the shooting.

Flexible to adapt to various video shooting situations.
The UE80 supports 4K/60p to render smooth high-resolution video images. With its wide 74.1° angle and optical 24x zoom, the camera captures details clearly even from a distance as well as the entire area from a limited space. It is equipped with many professional features and functions, including FreeD compatibility for connection to connect to AR/VR systems for virtual productions.

High quality video tranmission with low latency.
The UE80 supports High Bandwidth NDI®*1,2 for IP transmission of high-image-quality videos with a low latency, and NDI®|HX*3,4 for efficient video transmission even with a limited bandwidth, thus realizing stable video streaming. The UE80 offers high security, so it can be used safely in any video shooting.

  • Supports a wide variety of IP transmission protocols, including high bandwidth NDI*1, NDI|HX, and SRT*2
  • Supports 4K 50p/60p shooting
  • Includes a wide-angle lens with a 74.1° field of view and 24x optical zoom
  • Supports FreeD for building AR/VR systems
  • New Direct Drive System for improved responsiveness and quietness
  • RTMP/RTMPS for direct streaming
  • Use of Web GUI for camera control
SPECIFICATIONS
General Information
ManufacturerPanasonic
Manufacturer Part NumberAWUE80WPJ
Manufacturer Website Addresshttp://www.panasonic.com
Brand NamePanasonic
Product LineProfessional
Product ModelAW-UE80
Product NameAW-UE80 4K Professional PTZ Camera
Product TypeNetwork Camera
Technical Information
Recording Formats4K
HD RecordingYes
Night VisionYes
Night Vision TypeInfrared
Display & Graphics
Image Sensor TypeMOS
Image Sensor Size1/2.5"
Color SupportedColor
Field of ViewHorizontal angle of view: 74.1° (wide) to 3.3° (tele)Vertical angle of view: 46.0° (wide) to 1.9° (tele)Diagonal angle of view: 81.8° (wide) to 3.8° (tele)
Effective Camera Resolution8.4 Megapixel
Video
Video FormatsH.264
H.265
MJPEG
Maximum Video Resolution3840 x 2160
Maximum Frame Rate60 fps
Horizontal Resolution1500 TVL
Video Signal FormatPAL
NTSC
Analog Video Signal FormatNDI
SDI
3G-SDI
Lens
Lens TypeVarifocal
Minimum Focal Length4.10 mm
Maximum Focal Length98.90 mm
Lens IncludedYes
Minimum Aperturef/4
Maximum Aperturef/1.8
Optical Zoom24x
Exposure
Shortest Shutter Speed1/10000 Second
Longest Shutter Speed1/25 Second
Network & Communication
Connectivity TechnologyWired
ProtocolsRTMP
RTP
RTSP
SRTP
TCP
UDP
TCP/IP
UDP/IP
HTTP
HTTPS
DHCP
DNS
DDNS
NTP
IGMP
ICMP
ARP
DHCPv6
MLD
Remote ManagementYes
Interfaces/Ports
HDMIYes
Network (RJ-45)Yes
Power Description
Input Voltage12 V DC
Power Source TypePoE++
DC
PoE+
Physical Characteristics
Mount TypeCeiling Mount
Tripod Mount
Wall Mount
Pole Mount
Form FactorDome
Product ColorWhite
Environmental Conditions
Minimum Operating Temperature32°F (0°C)
Maximum Operating Temperature104°F (40°C)
Operating Humidity90%
Miscellaneous
FeaturesDay/Night
Gain Control
White Balance
Noise Detection
Mirror
Package Contents
  • AW-UE80 4K Professional PTZ Camera
  • Ceiling Mount
